Sigma Mixer Extruder Description

Sigma Mixer extruder

Sigma mixer extruder is used for Excellent for kneading and mixing of highly viscous materials like dough, putty, rubber solutions, adhesives, polymers etc. The mixing action is a combination of smearing, stretching, folding, dividing and recombining as the material is processed between the sigma blades and the container walls. Jacket arrangement is provided for heating or cooling application. In bigger models the container is tilted by a hydraulic cylinder to ensure complete discharge of mass.

ABF introduces the modern and heavy duty, strong built Sigma mixer (kneader) to produce uniform mixing and kneading heavier viscosity materials. The Sigma mixture is suitable for many applications like mixing, kneading, Grinding, dispersion, drying etc. The sigma mixer have application to produce highly viscous materials like different kinds of Chemical, Dyes & Pigments, Paint, Polymers Plastic, Putties, Plastic, Pharmaceuticals, Printing ink, stiff pastes, adhesives, polyester Compounds, flush colors, brake lining compounds, resign, soap, PVC coatings, Rubber compounds, Confectionery, Magnetic Tape Coatings, Ceramic, Carbon Black, dough, Food Products, Fiber Glass, Grease, Lead Storage Battery, Soap & Detergent etc.



SIGMA MIXER EXTRUDER – CAPACITY TABLE



Model No.

Working Capacity (Liter)

SHELL SIZE

Total Capacity (Liter)

MAIN GEAR BOX

Mixer (HP)

Extruder (HP)

ABFSME – 50

30 – 50

16” X 16”

75

4”

1.0 – 1.5

5 – 7.5

ABFSME – 75

50 – 75

20” X 20”

110

6”

15 – 20

5 – 7.5

ABFSME – 150

75 – 150

24” X 24”

200

8”

30 – 40

10 – 15

ABFSME – 300

150 – 300

36” X 36”

400

10”

40 – 50

10 – 15

**Note – The actual power consumption shall depend upon the application and the properties of the material to be mixed (Density, Viscosity etc.)

** Note – As improvements in design are being made continuously, the above specifications should be considered for reference only. The equipment built may differ due to our policy of continues product development.



Note : Working capacity to be calculated @ 60% of Total Capacity.

Get quote

Sigma Mixer Extruder

The Kneader Extruder combines the efficiency of a double arm – sigma blade mixer with the convenience of an extrusion screw for the mixing and discharging of heavy viscous materials. Such as Adhesives, Explosives, Mastics, Sealing compounds, Biscuit dough’s, Fiberglass resin dough’s, Metal powders, Silicone rubber, Butyl rubber, Food and confectionery products, Moulding preparations, Soaps and detergents, Carbon pastes, Gaskets and Gland Packing’s, Pencil erasers, Solid propellants, Ceramics Grinding wheel preparations, Pharmaceuticals, Sugar pastes, Chemicals, Hot-Melts, Plastics, Viscous rubber solutions, Chewing gum, Inks and pigment products, Putties, Crayon and pencil lead, Marzipan, Refractories.

The Kneader Extruder includes a set of counter-rotating kneading blades and a discharge screw. The blades are mounted on a horizontal axis in a u-shaped trough. Below the blades in a separate cavity is the discharge screw. During the mixing cycle the blades rotate toward each other while the mixing screw rotates in a reverse direction, constantly feeding new materials into the mixing blades. After the mixing/kneading cycle is complete, the screw is reversed and it transports the mixed materials from the mix zone out through a discharge die and on to further processing or packaging.

The Sigma Kneader Extruder has several advantages over conventional non-screw discharge kneaders:

  • Low mixing time approx. 15% less time.
  • Eliminates the manual task of scraping out sticky/tacky materials.
  • Eliminates operator exposure to materials of elevated temperatures or of a toxic nature, thereby improving plant safety.

Many Different sizes and designs are available to meet the most stringent process needs. Kneader Extruders are manufactured in many sizes from 5 through 2500 Liters capacity. Other sizes manufactured on request
